NETAPP Enterprise NVMe Solid State Drive - Model 108-00856 (X4010A-PM1733) Product Details

    1、 Product Overview

NETAPP 108-00856 (product model X4010A, disk body model PM1733) is a high-performance enterprise grade NVMe solid-state drive with a capacity of 1.92TB. The product uses advanced 3D TLC NAND flash technology and is designed specifically for read intensive workloads, achieving an excellent balance between performance, durability, and cost-effectiveness.

    2、 Technical specifications

Detailed specifications of parameter categories

Basic Parameters

Manufacturer model X4010A

NETAPP part number 108-00856

Disk model PM1733

Interface type NVMe over PCIe

Appearance specification 2.5 inches U.2

performance parameters

Nominal capacity 1.92TB

Available capacity 1.75TB (based on RAID configuration)

Sequential read speed up to 3400 MB/s

Sequential write speed up to 1500 MB/s

4K random read up to 450000 IOPS

4K random write up to 75000 IOPS

Delay read<85 μ s, write<18 μ s

Reliability parameters

Durability level 3 DWPD

Life indicator 10.5 PBW (lifetime write capacity)

MTBF 2, 000000 hours

Warranty period of 5 years or achieving durability indicators

    3、 Core technical features

    1. Optimized read performance

Adopting PCIe 3.0/4.0 x4 interface

Specially optimized for read operations

Design of Low Power High Performance Controller

Supports NVMe 1.3/1.4 standards

    2. Enterprise level reliability

Typical power consumption: 8-10W

Maximum power consumption: 14W

Integrated power-off protection function

End to end data path protection

    3. Intelligent management function

Support hot plug operation

Online firmware upgrade capability

Advanced S.M.A.R.T. monitoring

Temperature adaptive performance adjustment

    4、 Compatibility information

Supported system models:

AFF A220, A250, A400 series

FAS500f, FAS8300 series

Supports ONTAP 9.5 and higher versions

AFF A series controller

Supports standard 2.5-inch disk slots

    5、 Application scenarios

    1. Read intensive applications

Virtual Desktop Infrastructure (VDI)

Content Delivery Network (CDN)

Data analysis and report query

Web server storage

    2. Enterprise level applications

Database Read Copy

Application server storage

file share service

Email server storage

    3. Cloud service scenarios

Virtual machine image storage

Container persistent storage

Backup and archive storage

Development and testing environment
