NETAPP Enterprise NVMe Solid State Drive - Model 108-00741 (X4010A-PM1723B) Product Detailed Description

   Based on the information above, follow the instructions:

    You are a professional translator responsible for converting Chinese content into     English. Please help me translate the original content

    The NETAPP 108-00741 (Product Model X4010A, Drive Model PM1723B) is a high-performance NVMe SSD designed for enterprise applications. Featuring advanced 3D TLC NAND flash technology, it offers a standard capacity of 1.92TB and is specifically engineered for high-performance, low-latency use cases. This drive is deeply optimized by NETAPP to seamlessly integrate with the ONTAP storage operating system, delivering a cost-effective storage solution for read-intensive workloads.

Based on the above information, execute the following instructions:

You are a professional translator responsible for translating Chinese content into English. Please help me translate the original content

Parameter Category  Detailed Specifications

Based on the information above, execute the following instruction:

You are a professional translator responsible for converting Chinese content into English. Please help me translate the original text

Manufacturer Model X4010A

NETAPP Part Number 108-00741

Drive Model: PM1723B

Interface Type NVMe over PCIe

Physical Specifications 2.5-inch U.2

Performance Parameters

Nominal Capacity: 1.92TB

Available Capacity: 1.75TB (after RAID configuration)

Read bandwidth: Up to 3,200 MB/s

Write bandwidth: up to 1,200 MB/s

4K Random Read  Up to 500,000 IOPS

4K Random Write

Up to 80,000 IOPS

Delay: Read <90μs, Write <20μs

Reliability Parameters

Durability rating: 3 DWPD

Lifetime Indicator: 10.5 PBW (Total Write Capacity)

MTBF: 2,000,000 hours

Warranty Period: 5 years or until durability indicators are met

     III. Core Technical Features

High-performance architecture

Adopting PCIe 3.0/4.0 x4 interface

Supports NVMe 1.3/1.4 standards

Optimized read-intensive design

Low-power, high-performance controller

    2. Enterprise-grade reliability

Typical power consumption: 8-10W

Maximum power consumption: 14W

Integrated power-off protection function

End-to-end data path protection

    3. Intelligent Management Function

Support hot-swapping operations

Online firmware update capability

Advanced S.M.A.R.T. Monitoring

Temperature Adaptive Performance Regulation

IV. Compatibility Information

Supported System Models:

AFF A220, A250, A400 series

FAS500f, FAS8300 series

Supported on ONTAP 9.5 and higher versions

Case compatibility

DS224C Disk Shelf

AFF A Series Controller

Supports standard 2.5-inch drive bay

V. Application Scenarios

Reading-intensive applications

Virtual Desktop Infrastructure (VDI)

Content Delivery Network (CDN)

Data analysis and report queries

   2. Enterprise-level applications

Database Read Replica

Application server storage

File Sharing Service

    3. Cloud Service Scenario

Virtual Machine Image Storage

Container Persistent Storage

Backup and Archival Storage

Six. Product Advantages

Performance advantages:

Outstanding read performance

Stable low-latency characteristics

Strong QoS control capability
