QLogic QLE2460/QLE2460-CK Fiber Channel HBA Product Introduction

overview

           QLogic QLE2460 is a high-performance 4Gb/s Fibre Channel host bus adapter designed specifically for enterprise storage area networks (SANs). It supports high-speed, low latency data transmission and is suitable for critical business applications such as databases, virtualization, disaster recovery, etc. Its derivative model QLE2460-CK is usually a customized version for specific customers or channels, with hardware functions basically the same as the standard version.

Key Features

         high-performance connections

         Supports 4Gb/s fiber channel (backward compatible with 2Gb/s and 1Gb/s).

          Full duplex transmission provides stable bandwidth and low latency.

          hardware optimization

          Integrated QLogic ISP2432 controller chip, providing hardware level data acceleration and load balancing.

          Supports PCI Express 1.0a x4 interface and is compatible with mainstream server architectures.

         high reliability

          Support multi-path I/O (MPIO) and link aggregation to ensure redundancy and failover.

         Compliant with FC-PI-2, FC-FS-2 and other fiber channel standards, compatible with mainstream storage devices such as EMC, NetApp, HPE, etc.

flexible configuration

        Single port (QLE2460) and dual port (QLE2462) models are available for selection.

Supports SFP (LC interface) fiber optic modules, suitable for short wave (SWL) or long wave (LWL) transmission.

Operating System compatibility

          Supports mainstream operating systems such as Windows Server, Linux, VMware iPadOS, Solaris, etc.

Application scenarios

          Enterprise level SAN storage network connectivity.

           Virtualization environments (such as VMware HANA, Microsoft Hyper-V).

           High availability clusters and databases (Oracle RAC, SQL Server).
