HPE P02434-003 (PM1643) 3.84TB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

    HPE P02434-003 (disk body model PM1643) is a high-performance enterprise NVMe solid-state drive that uses HPE's self-developed enterprise level solution. This hard drive is designed specifically for enterprise critical business systems that require high-performance storage, achieving the best balance between performance, capacity, and reliability, and is suitable for application scenarios such as databases, virtualization, and cloud computing.

1. Core features and specifications

Capacity specification: 3.84TB

(Adopting intelligent capacity management technology and optimizing OP configuration to the optimal state)

Interface protocol: NVMe 1.3 over PCIe 3.0 x4

Appearance specification: 2.5 inches U.2 (SFF-8639)

Performance performance:

Continuous reading speed: up to 3200 MB/s

Continuous write speed: up to 2000 MB/s

Random read IOPS: up to 580000 (4K)

Random write IOPS: up to 115000 (4K)

Durability index:

DWPD: 1.0 (5-year warranty period)

TBW：7.0PB

MTBF: 2.5 million hours

Flash Memory Type: 3D eTLC NAND

(Using enterprise grade enhanced TLC flash memory to provide excellent durability)

2. Advanced features

Intelligent power management:

Multi level power consumption state management

Integrated Advanced Power Failure Protection (PLP) Circuit

Power efficiency increased by 25%

Data Protection:

End to end data path protection

Enhanced ECC Error Correction Algorithm

RAID level data protection function

Performance optimization:

Intelligent pre reading and caching algorithm

QoS Service Quality Control

Adaptive read-write scheduling

Thermal management:

Multi point temperature monitoring

Dynamic temperature control regulation

Overheating protection mechanism

3. Applicable scenarios

Enterprise level database:

Oracle database system

sql server database

MySQL cluster deployment

Virtualization platform:

VMware HANA environment

Microsoft Hyper-V Platform

Containerized application storage

Cloud computing:

Private cloud storage resource pool

Hybrid cloud storage solution

Cloud native application storage

Big data analysis:

Real time data processing

Data warehouse storage

Business Intelligence Analysis

4. Compatibility information

Support platform:

HPE ProLiant DL360 Gen10

HPE ProLiant DL380 Gen10

HPE Apollo 4200 System

HPE Synergy 480 System

System requirements:

UEFI 2.4 or higher version

NVMe 1.3 protocol support

PCIe 3.0 x4 interface

Management tools:

HPE iLO 5 Management Suite

HPE OneView Management Platform

HPE InfoSight analysis tool
