HPE P06042-005 (KIOXIA) 3.84TB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

   HPE P06042-005 (using Kaixia Enterprise Flash) is a high-performance enterprise NVMe solid-state drive that utilizes the latest PCIe 4.0 technology and Kaixia BiCS FLASH 3D TLC flash. This hard drive is designed specifically for the high-performance requirements of modern data centers, achieving the best balance between performance, capacity, and energy efficiency, and is suitable for application scenarios such as cloud computing, artificial intelligence, and big data analysis.

1. Core features and specifications

Capacity specification: 3.84TB

(Adopting intelligent capacity management and OP configuration optimization)

Interface protocol: NVMe 1.4 over PCIe 4.0 x4

Appearance specification: 2.5 inches U.2 (SFF-8639)

Performance performance:

Continuous read speed: up to 6900 MB/s

Continuous write speed: up to 4200 MB/s

Random read IOPS: up to 1300000 (4K)

Random write IOPS: up to 250000 (4K)

Durability index:

DWPD: 1.5 (5-year warranty period)

TBW：10.5PB

MTBF: 2.5 million hours

Flash type: BiCS FLASH 3D TLC NAND

(Using the fifth generation 3D flash memory technology of Kaixia)

2. Advanced features

Intelligent power management:

Support NVMe MI 1.2 management interface

Multi level power consumption state automatic switching

Data Protection:

End to end data path protection

Enhanced LDPC Error Correction

RAID protection mechanism

Performance optimization:

Intelligent pre read cache

QoS Service Quality Control

Adaptive read-write scheduling

Security management:

AES 256 bit hardware encryption

TCG Opal 2.01 Safety Standard

Secure erase function

3. Applicable scenarios

Cloud computing platform:

Virtual Machine Storage

Container storage

Cloud Block Storage

artificial intelligence:

Machine learning training

Deep Learning Reasoning

Model storage

Big data analysis:

Real time data processing

data warehouse

stream computing

Enterprise applications:

database system

virtualization platform

File Service

4. Compatibility information

Support platform:

HPE ProLiant DL360/380 Gen10+

HPE ProLiant DL325/385 Gen10+

HPE Apollo 2000/4000 System

HPE Synergy 480/660 system

System requirements:

UEFI 2.8 or higher version

NVMe 1.4 protocol support

PCIe 4.0 x4 interface

Management tools:

HPE iLO 6

HPE OneView

HPE InfoSight
