Product Overview

Original All Flash Storage Solution | 4.8TB NVMe PCIe 4.0 Enterprise Solid State Drive (Complete Component Number: 03GH824-03GU518) - Provides high-performance and highly reliable storage assurance for critical business needs of enterprises

2.Core advantages

Excellent performance

Adopting NVMe PCIe 4.0 interface protocol, the sequential read speed reaches up to 7200 MB/s, the sequential write speed reaches 4800 MB/s, and the random read/write performance exceeds 1.8M IOPS, providing the ultimate performance experience for enterprise level applications

Intelligent cooling system

Equipped with original heat dissipation bracket (03GU518), adopting dual fan active heat dissipation design to ensure optimal temperature under full load operation and prevent performance degradation

Authentic Quality Certification

Specially designed for FlashSystem 9200/9500 optimization, ensuring perfect compatibility and stability with storage systems through rigorous quality testing

Optimize capacity design

4.8TB capacity perfectly balances performance and storage requirements, with a single disk capable of meeting the needs of medium-sized databases and virtualization environments

Enterprise level reliability

Supports 24/7 uninterrupted operation, with an annual write capacity of 3 DWPD and a warranty life of 5 years or 26.3 PBW

3.Technical specifications

Detailed specifications of parameter categories

Hard drive model 03GH824

Bracket model 03GU518

Storage capacity 4.8TB

Interface standard NVMe PCIe 4.0 x4

Appearance specification 2.5 inches U.2

Flash Memory Type: 3D TLC NAND

Includes NVMe drive body and original heat dissipation bracket (03GU518)

Read and write performance: Sequential read: 7200 MB/s | Sequential write: 4800 MB/s

Durability index 3 DWPD (5 years/26.3PBW)

Compatible with IBM FlashSystem 9200/9500 series

4.Compatible system

Perfect compatibility platform:

FlashSystem 9200

FlashSystem 9500

DS8900F

Storage Virtualize 8.5 and above versions

Spectrum Virtualize

5.Application scenarios

Enterprise level key applications:

Database Acceleration - Performance Enhancement of Key Databases such as Oracle RAC and SQL Server

Virtualization Platform - VMware HANA, Hyper-V Virtualization Environment Storage

Private Cloud Construction - OpenStack, CloudStack Cloud Platform Storage Infrastructure

Artificial Intelligence - Machine Learning Model Training and Reasoning Data Storage

Real time analysis - Financial real-time risk control and trading analysis platform

Media Processing -4K/8K Video Editing and Rendering Workflow

6.Quality Assurance

100% original components, providing genuine verification

Pass 120 hour high-temperature aging test

Provide a complete SMART health status report

Professional technical support services

Support machine validation testing

7.Installation requirements

system requirements

Requires support for IBM Storage Virtualize 8.5 or higher versions

Firmware Version

Must upgrade to the latest IBM system firmware version

environmental conditions

Operating temperature: 5°C to 40°C

Storage temperature: -40°C to 70°C

Humidity: 8% to 90% non condensing

Installation recommendations

Suggest installation and configuration by technical personnel

8.Service Support

Professional technical consultation - providing complete technical specifications and compatibility guidance

Installation and configuration support - provide detailed installation and configuration documentation

Batch purchase discount - supports enterprise level batch purchase needs

Quick Response Service - Professional Technical Team with 24/7 Support

Spare parts guarantee - providing fast spare parts replacement services
