Product Overview

This is an enterprise-class NVMe SSD that offers up to 3.84TB of raw capacity on a single disk. The chassis is available in a standard 2.5-inch U.2 form factor and is designed to meet the demands of modern data centers and high-end enterprise servers for extreme I/O performance and reliability. Models 01NN772 and 01NN773 are usually the same disk, which may vary slightly depending on sales channels, accessory packages, or firmware versions, but the core hardware specifications are identical.
2.Core specifications and parameters
Parameter Item Parameter details
Product model 01NN772 / 01NN773
Capacity 3.84 TB (Approx. 3.8TB after formatting)
Interface Protocol NVMe 1.2 (Non-Volatile Memory High-Speed Protocol)
Physical interface PCIe 3.1 x4 (backwards compatible)
Form Factor 2.5" U.2 (formerly SFF-8639)
Storage media 3D TLC NAND flash memory
Workload Type Read-Intensive
Endurance (DWPD) Approx. 1 DWPD (Full Disk Writes per Day, 5-Year Warranty)
Sequential Read Speeds up to 3,200 MB/s (typical)
Sequential write speeds up to 1,800 MB/s (typical)
Random Read Speeds up to 500,000 IOPS (4K, typical)
Random write speeds up to 40,000 IOPS (4K, typical)
Mean Time Between Failures 2 Million Hours (MTBF)

3.Main features and advantages
Extreme Performance:
With the NVMe over PCIe architecture, it completely eliminates the bandwidth bottleneck of traditional SATA/SAS interfaces, provides extremely low latency and ultra-high throughput, and can significantly accelerate data access and improve application responsiveness.
Enterprise-grade reliability:
Designed for 24/7 enterprise environments. The 2 million hours MTBF and 5-year warranty provide a long-term quality guarantee.
It supports end-to-end data path protection, advanced power loss protection (PLI), and more, ensuring data integrity and security in any unexpected situations.
Intelligent Management:
It can be perfectly integrated with ProLiant, Apollo, and other servers.
InfoSight predictive analytics is supported, which can actively monitor the health of the drive, warn of potential faults in advance, and achieve intelligent O&M.
Superior Quality:
It has undergone rigorous testing and verification to ensure 100% compatibility and stability with the server system, avoiding compatibility issues and performance bottlenecks that may occur when using third-party hard drives.
4.Applicable scenarios
Database Acceleration: Ideal as primary storage for large databases such as Oracle, SQL Server, SAP HANA, etc.
Virtualization Platform: Provides high-performance storage for virtualized environments such as VMware, Hyper-V, and KVM, supporting more virtual machines and improving operational efficiency.
High-performance computing: Meet HPC scenarios that require high-speed data reading and writing, such as financial analysis, scientific research, and AI/ML training.
Server boot disk: Acts as the boot drive of the operating system, greatly reducing server boot and application load times.
Content Delivery Network: Used for CDN nodes that need to read and transmit large amounts of static content quickly.
5.Compatibility information
The drive is designed to be compatible with a wide range of mainstream server models, including (but not limited to):
ProLiant DL series: DL360 Gen10, DL360 Gen10 Plus, DL380 Gen10, DL380 Gen10 Plus, etc.
ProLiant BL Series: BL460c Gen10 and more.
Apollo Series: Apollo 2000, Apollo 4000, Apollo 6000 systems.
Synergy Compute Module.
Note: Please ensure that your server chassis supports NVMe U.2 hard drive slots and runs the latest firmware and drivers for optimal compatibility before use.
6.Purchase suggestions
When purchasing this disk for replacement or expansion, be sure to confirm your server model and supported drive types.
It is recommended to use it in pairs or as a RAID to ensure data security and high availability.
