EMC Enterprise NVMe Solid State Drive - Model 118000632/005052584  Product Detailed Description

1. Product Overview

The EMC 118000632/005052584 (Model PM1643) is a high-performance enterprise-grade NVMe SSD with a capacity of 1.92TB. Utilizing advanced 3D TLC NAND flash technology, this product is based on PCIe interfaces and NVMe protocols, delivering reliable performance for enterprise workloads. It serves as an ideal choice for building modern storage infrastructure.

II. Detailed Technical Specifications

Parameter Category  Detailed Specifications

Basic Information

EMC Part Number 118000632/005052584

Disk Model: PM1643

Flash memory type: 3D TLC NAND

Interface Protocol: NVMe over PCIe 3.0

Physical dimensions: 2.5-inch U.2

Capacity information

Nominal Capacity 1.92TB

Available user capacity ≈1.75TB

Performance parameters

Sequential read speed: 3,200 MB/s

Sequential write speed: 1,800 MB/s

4K Random Read: 600,000 IOPS

4K Random Write 150,000 IOPS

Read/Write Latency: Read <90μs, Write <20μs

Reliability parameters

Durability Rating: 3 DWPD

Service life 10.5 PBW

Mean Time Between Failures: 2,000,000 hours

Warranty Policy: 5-Year Limited Warranty

III. Core Technologies and Features

1. High-performance architecture

PCIe 3.0 x4 interface

NVMe-optimized protocol stack

High-performance flash memory controller

Support for multiple namespaces

2. Enterprise-level reliability

Power Failure Protection Mechanism: Data Integrity Assurance

End-to-end data protection: complete verification mechanism

Advanced Error Correction: LDPC Error Correction Technology

Smart Wear Leveling: Extend Lifespan

3. Smart Management Function

Hot-swap support: Online maintenance capability

Health Status Monitoring: S.M.A.R.T. Attributes

Temperature Management: Dynamic Thermal Regulation

Remote Management: Standard Management Interface

IV. Compatibility Information

Supported Dell EMC Systems:

Unity Series Storage Arrays

PowerEdge series servers

VxRail Hyper-Converged System

Specific model of PowerMax system

Operating System Support:

VMware vSphere 6.7 or later

Windows Server 2016/2019

Red Hat Enterprise Linux 7/8

SUSE Linux Enterprise Server 12/15

V. Recommended Application Scenarios

1. General enterprise workloads

Virtualization Platform Storage

Medium-sized database applications

File Sharing Service

2. Cloud Infrastructure

Virtual Machine Image Storage

Container persistent storage

Development and Testing Environment

3. Commercial Applications

Mail server storage

Web application storage

Collaboration Platform Storage

4. Data Protection

Backup Storage Acceleration Layer

Disaster Recovery Storage

Data Tiered Storage

VI. Summary of Product Advantages

Performance advantage

Balanced read and write performance

Stable low latency

Excellent IOPS performance

Reliability advantage

Enterprise-grade durability design

Comprehensive data protection

long life cycle

Cost advantage

Optimized total cost of ownership

High-Efficiency Design

Low maintenance cost

7. Environmental Specifications

Parameter  Specification

Operating temperature: 0°C to 55°C

Storage temperature: -40°C to 70°C

Operating humidity: 8% to 90% non-condensing

Typical power consumption: 8-10W

Maximum power consumption: 15W

Vibration resistance

Compliant with enterprise-level standards
