EMC Enterprise NVMe Solid State Drive - Model 118000839 005053704 Product Details

1、 Product Overview

EMC 118000839 005053704 (part number: 005053081, disk body model PM1723B) is a high-capacity enterprise grade NVMe solid-state drive with a capacity of up to 7.68TB. The product uses advanced 3D TLC NAND flash technology, based on PCIe 4.0 interface and NVMe protocol, designed specifically for the ultimate performance requirements of modern data centers, setting new industry standards in storage density, performance, and reliability.

2、 Detailed technical specifications

Detailed specifications of parameter categories

Basic Information

EMC part number 118000839 005053704

Alternative part number 118000839 005053704

Disk model PM1723B

Flash technology 3D TLC NAND

Interface protocol NVMe 1.4 over PCIe 4.0

Appearance specification 2.5 inches U.2 (15mm thickness)

Capacity information

Nominal capacity 7.68TB

User available capacity ≈ 7.0TB

performance parameters

Sequential read speed 7100 MB/s

Sequential write speed 4300 MB/s

4K random read 1500000 IOPS

4K random write 320000 IOPS

Read/write delay: Read<65 μ s, write<9 μ s

Reliability parameters

Durability level 3 DWPD

Service life 84 PBW

Mean time between failures 2500000 hours

Annual failure rate 0.35%

Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

1. Innovative architecture design

PCIe 4.0 x4 interface, providing a transfer rate of 16 GT/s

Support multiple namespaces and SRIOV virtualization

Optimized parallel processing architecture

High performance low-power controller

2. Enterprise level reliability engineering

Enhanced power-off protection: multi-layer supercapacitor array

End to end data protection: complete data path protection

Advanced LDPC Error Correction: Fourth Generation LDPC Error Correction Technology

Intelligent Health Monitoring: Real time Flash Health Management System

3. Intelligent management function

Hot swappable support: Compliant with NVMe hot swappable standards

Telemetry: Real time performance monitoring and analysis

Intelligent Temperature Control: Multi zone Dynamic Temperature Management

Remote management: NVMe MI 1.2 management interface

4、 Compatibility information

Supported Dell EMC Systems:

PowerMax 2500/8500 Full Flash Array

Unity XT 680F/880F hybrid storage

PowerEdge MX series modular servers

VxRail P-series hyper fusion system

Software environment support:

VMware HANA 7.0 U3 and above

Windows Server 2022

Red Hat Enterprise Linux 8.5 and above

SUSE Linux Enterprise Server 15 SP3

5、 Recommended application scenarios

1. Ultra large scale data center

Hyper converged infrastructure

Software defined storage platform

Cloud service provider infrastructure

2. Key business of the enterprise

Ultra large database system

Enterprise level data warehouse

Key business application storage

3. Artificial Intelligence and Big Data

AI training platform storage

Machine learning workloads

Big data analysis platform

4. High performance computing

Scientific research computation

Financial modeling analysis

4K/8K video processing

6、 Summary of Product Advantages

Capacity advantage

Industry leading storage density

Optimized spatial efficiency

Significantly reduce overall cost of ownership

performance advantage

PCIe 4.0 Ultimate Performance

Ultra low latency response

Excellent throughput capability

Reliability advantage

Enterprise level durability design

A comprehensive data protection mechanism

Predictive maintenance capability

7、 Environmental specifications

Parameter specifications

Working temperature: 0 ° C to 55 ° C

Storage temperature -40 ° C to 85 ° C

Working humidity 5% to 95% non condensing

Working altitude 3050 meters

Typical power consumption 14-16W

Maximum power consumption 26W

Impact resistance 1000G (0.5ms)

     Huaxing Xintongcan provide sales of a large number of new or used transmission equipment, servers, communication power systems, routers, base station equipment, switches, SFPs, storage devices, and other communication products. We have extensive knowledge and experience in product operation and maintenance. We have multiple professional technical personnel to provide testing for our products, ensuring that every refurbished spare part is perfect. It can reduce costs for your network maintenance. Looking forward to working with you.
