EMC Enterprise NVMe Solid State Drive - Model 118000596-03 Product Details

     1、 Product Overview

EMC 118000596-03 (using Intel flash technology) is a high-performance enterprise NVMe solid state drive with a capacity of 1.5TB. The product is based on Intel's premium flash technology and is designed specifically for enterprise mixed workloads, achieving an excellent balance between performance, durability, and cost-effectiveness, making it suitable for a variety of enterprise storage application scenarios.

     2、 Detailed technical specifications

Detailed specifications of parameter categories

Basic Information

EMC part number 118000596-03

Flash technology Intel 3D NAND

Interface Protocol NVMe over PCIe 3.0

Appearance specification 2.5 inches U.2

Capacity information

Nominal capacity of 1.5TB

Available capacity ≈ 1.37TB

performance parameters

Sequential read speed 3200 MB/s

Sequential write speed of 1600 MB/s

4K random read 500000 IOPS

4K random write 90000 IOPS

Read/write delay: Read<85 μ s, write<15 μ s

Reliability parameters

Durability level 3 DWPD

Optimized flash controller architecture

Supports PCIe 3.0 x4 interface

Low power and high-performance design

    2. Enterprise level reliability

Power outage protection mechanism: data integrity guarantee

End to end data protection: complete verification mechanism

Advanced Error Correction: LDPC Error Correction Technology

Wear Balance Algorithm: Intelligent Life Management

     3. Intelligent management function

Hot swappable support: online maintenance capability

Health status monitoring: S.M.A.R.T. attribute

Temperature Management: Dynamic Temperature Control Adjustment

Firmware Management: Online Upgrade Support

     4、 Compatibility information

Supported Dell EMC Systems:

PowerEdge series servers

VxRail hyper fusion system

Unity hybrid storage array

PowerMax All Flash Array

Operating system support:

Windows Server 2016/2019/2022

Red Hat Enterprise Linux 7/8

VMware ESXi 6.7/7.0

SUSE Linux Enterprise Server 12/15

    5、 Recommended application scenarios

1. General enterprise workloads

Virtualization platform storage

Medium sized database applications

File sharing service

   2. Cloud infrastructure

Virtual machine image storage

Container persistent storage

Development and testing environment

   3. Commercial applications

Email server storage

Web application storage

Collaborative platform storage

     4. Data Protection

Backup storage acceleration layer

Disaster recovery storage

Data archiving and storage

    5 、 Summary of Product Advantages

performance advantage

Balanced read and write performance

Stable low latency

Good IOPS performance

Reliability advantage

Intel High Quality Flash Memory

Enterprise level durability design

Comprehensive data protection

cost advantage

Optimized total cost of ownership

High energy efficiency design

Long term operational reliability

    6、 Environmental specifications

Parameter specifications

Working temperature: 0 ° C to 55 ° C

Storage temperature -40 ° C to 70 ° C

Working humidity 8% to 90% non condensing

Working altitude of 3000 meters

Typical power consumption of 8-10W

Maximum power consumption 15W

Anti vibration 4.0 Grms (5-700 Hz)
