HPE 850333-001 (PM1633a) 7.68TB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

     HPE 850333-001 (disk model PM1633a) is a high-performance, high-capacity enterprise NVMe solid-state drive that utilizes an enterprise level solution developed in collaboration with leading flash memory manufacturers. This hard drive is designed specifically for enterprise critical business systems that require high-performance and large capacity storage, achieving the best balance between performance, capacity, and reliability. It is suitable for applications such as virtualization, databases, and cloud computing.

1. Core features and specifications

Capacity specification: 7.68TB

(Adopting enterprise level reserved space design, OP configuration ensures long-term performance stability)

Interface protocol: NVMe 1.3 over PCIe 3.0 x4

Appearance specification: 2.5 inches U.2 (SFF-8639)

Performance performance:

Continuous reading speed: up to 3200 MB/s

Continuous write speed: up to 2000 MB/s

Random read IOPS: up to 750000 (4K)

Random write IOPS: up to 110000 (4K)

Durability index:

DWPD: 1.0 (5-year warranty period)

TBW：14.0PB

MTBF: 2 million hours

Flash Memory Type: 3D TLC NAND

(Using advanced 3D stacking technology to provide excellent capacity and performance balance)

2. Advanced features

Enterprise level power protection:

Integrated power outage protection (PLP) circuit ensures data integrity in case of abnormal power outage

End to end data protection:

Adopting advanced ECC checksum and metadata protection mechanism

Intelligent wear balance:

Support dynamic and static wear balance to extend service life

Thermal management function:

Built in temperature sensor, supporting adaptive temperature control adjustment

Secure encryption:

Supports AES 256 bit hardware encryption, compliant with security standards

3. Applicable scenarios

Enterprise level database:

Large scale database storage such as Oracle and SQL Server

Virtualization platform:

VMware HANA, Microsoft Hyper-V virtualization environment

Cloud computing:

Primary storage for public and private cloud platforms

Big data analysis:

Real time data processing and analysis applications

Media storage:

Video editing and content creation storage

4. Compatibility information

Support platform:

HPE ProLiant DL360 Gen10

HPE ProLiant DL380 Gen10

HPE Apollo 4200

HPE Synergy 480 Gen10

System requirements:

UEFI 2.4 or higher version is required

Supports NVMe 1.3 and above protocols

Management tools:

Remote monitoring can be achieved through HPE iLO 5

Support HPE OneView unified management
