HPE 850333-002/867544-001 (PM1633a) 15.36TB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

     HPE 850333-002/867544-001 (disk model PM1633a) is a high-capacity enterprise NVMe solid-state drive that utilizes an enterprise level solution developed in collaboration between HPE and Samsung. This hard drive is designed specifically for critical business systems in enterprises that require the ultimate storage capacity. It provides exceptional performance while offering massive capacity, making it suitable for applications such as big data analysis, cloud storage, and media processing.

1. Core features and specifications

Capacity specification: 15.36TB

(Adopting advanced 4K page management and intelligent reservation space technology)

Interface protocol: NVMe 1.3 over PCIe 3.0 x4

Appearance specification: 2.5 inches U.2 (SFF-8639)

Performance performance:

Continuous reading speed: up to 3200 MB/s

Continuous write speed: up to 2200 MB/s

Random read IOPS: up to 800000 (4K)

Random write IOPS: up to 120000 (4K)

Durability index:

DWPD: 1.0 (5-year warranty period)

TBW：28.0PB

MTBF: 2 million hours

Flash Memory Type: 3D V-NAND TLC

(Using the sixth generation 3D stacking technology, the storage density is increased by 40%)

2. Advanced features

Enterprise level power protection:

Integrated supercapacitor protection circuit ensures data integrity in case of abnormal power outage

End to end data protection:

Adopting a 128 bit CRC checksum and metadata protection mechanism

Intelligent wear balance:

Support dynamic and static wear balance to extend service life

Thermal management function:

Built in multiple temperature sensors, supporting adaptive thermal throttling

Secure encryption:

Supports AES 256 bit hardware encryption, compliant with security standards

3. Applicable scenarios

Big data analysis:

Massive data storage and real-time analysis and processing

Cloud storage services:

Large capacity storage pools for public and private clouds

Media Entertainment:

8K video production and media content storage

Virtualization platform:

High density virtual machine deployment environment

Archive storage:

High performance data archiving solution

4. Compatibility information

Support platform:

HPE ProLiant DL360 Gen10

HPE ProLiant DL380 Gen10

HPE Apollo 4200

HPE Synergy 480 Gen10

System requirements:

UEFI 2.4 or higher version is required

Supports NVMe 1.3 and above protocols

Management tools:

Remote monitoring can be achieved through HPE iLO 5

Support HPE OneView unified management
